• Inputs
  • 1; for connecting potential-free contacts (switches, buttons, relays)
• Outputs
  • 1
• Integrated logic module
  • Yes
• Integrated configuration backup
  • Yes
• Comfort and timer functions
  • Yes
• Microphone
  • Yes
• Loudspeaker
  • Yes
• Proximity sensor
  • Yes, maximum range 1 metre
• Room temperature sensor
  • Yes
• Light sensor
  • Yes
• Switching capacity
  • 1200 W / 1200 VA (220-240 V~) 600 W / 600 VA (110-219 V~)
• Sound encoder
  • No
• Intercom function
  • No
• Passive infrared sensor (PIR sensor)
  • Yes
• Dimensions (L x B x H)
  • 81 × 81 × 12
• Mains voltage
  • AC 110–240 V~
• Mains frequency
  • 50 / 60 Hz
• Stand-by consumption
  • 1 Watt
• WLAN
  • No
• Bluetooth®
  • Bluetooth® 4.2 Low Energy
• Frequency range
  • 2400-2483,5 MHz max. 0,1 dBm
• Typical radio open field range
  • 30 Meter
• Ambient temperature
  • –25° to +55°C
• Storage temperature
  • –25°C bis +70°C
• Air humidity (during operation)
  • (Non-condensing)
• Type of contact
  • μ, closing contact
• Connection variants
  • potential-free switches/buttons, lamps, inductive load, electronic transformers
• Connection type
  • Spring-type terminal (single wire)
• Core cross-section
  • 1 - 1,5 mm2 (rigid, flexible without ferrule) / 0,2 - 0,5 mm2 (rigid)
• Stripping length
  • 8 mm (1–1,5 mm²) / 6 mm (0,2–0,5 mm²)
• Max. Cable length of the inputs ø 0,5mm²
  • 100 m
• Packaging size
  • 1 unit, 10 units
• EAN 1 unit
  • 4260578530323
• Packaging dimensions (L x B x H) 1 Stück
  • 140 × 130 × 60 mm
• Weight including packaging 1 unit
  • 275 g
• Mounting type
  • Surface mounted (in device socket according to DIN 49073)
• Weight
  • 145 g
