frogStrip120e
Add a new review
4-channel control module for LED strips (RGBW, RGB, Tunable White or Unicolor) for connection of an external 12-24 VDC constant voltage supply, max 12 V / 5 A or 24 V / 5 A, with 2 contact inputs for querying floating pushbuttons/switches and integrated time buffering. With comfort and time functions.
1Brand: frogblue
SKU:
900.000088
Category:
The frogStrip120e with integrated MultiStrip technology allows the connection of one RGBW LED strip as well as the simultaneous operation of several different LED strips.
For example, four individual white light strips or one RGB and one white light strip can be operated independently of each other on one controller. Likewise, two tunable white strips with 2 channels each can be connected.
It features intelligent strip power management, which distributes the power between the channels in such a way that even longer LED strips can be operated in an energy-saving manner on just one controller.
When operating several different LED strips on one controller, the power distribution between the LED strips can be adjusted. For example, in a piece of furniture with white interior lighting and RGB counter lighting, only one LED controller can be used to lower the counter lighting while maintaining the same color when the interior lighting is needed. This reduces the number of power supplies and controllers.
Easy installation
The LED controller does not require a central processing unit and can be operated stand-alone. The LED controllers can be integrated into a frogblue smart home system via the integrated Bluetooth®.
Switches, pushbuttons, reed or door contacts can be connected to the two inputs for control (edge or level controlled).
Simple operation
The inputs on the LED controller can be freely configured with several functions. Thus, with a push button, the light can be switched on/off, the color can be controlled and the brightness can be adjusted. The LED controllers communicate with each other via the frogblue Bluetooth® mesh network and can be controlled from anywhere in the house. Fully automatic and logically linked. Via the frogblue HomeApp on the smartphone/tablet or frogDisplay, brightness and color can be easily adjusted and, for example, an atmospheric lighting for the room or the whole house can be realized with just one click (scene).
With the frogblue one-button remote control frogKey all functions of the LED controller can be controlled remotely.
Further advantages and functions
Synchronous switching and dimming via several LED controllers Time-controlled switching on and off Soft On/Off (soft switching on and off) Delayed switching on and off Energy-efficient and durable with extremely low heat generation Integrated logic module with unlimited IF-THEN functions in the system, e.g. different brightness during the day than at night or e.g. flashing function when the doorbell is pressed.
For example, four individual white light strips or one RGB and one white light strip can be operated independently of each other on one controller. Likewise, two tunable white strips with 2 channels each can be connected.
It features intelligent strip power management, which distributes the power between the channels in such a way that even longer LED strips can be operated in an energy-saving manner on just one controller.
When operating several different LED strips on one controller, the power distribution between the LED strips can be adjusted. For example, in a piece of furniture with white interior lighting and RGB counter lighting, only one LED controller can be used to lower the counter lighting while maintaining the same color when the interior lighting is needed. This reduces the number of power supplies and controllers.
Easy installation
The LED controller does not require a central processing unit and can be operated stand-alone. The LED controllers can be integrated into a frogblue smart home system via the integrated Bluetooth®.
Switches, pushbuttons, reed or door contacts can be connected to the two inputs for control (edge or level controlled).
Simple operation
The inputs on the LED controller can be freely configured with several functions. Thus, with a push button, the light can be switched on/off, the color can be controlled and the brightness can be adjusted. The LED controllers communicate with each other via the frogblue Bluetooth® mesh network and can be controlled from anywhere in the house. Fully automatic and logically linked. Via the frogblue HomeApp on the smartphone/tablet or frogDisplay, brightness and color can be easily adjusted and, for example, an atmospheric lighting for the room or the whole house can be realized with just one click (scene).
With the frogblue one-button remote control frogKey all functions of the LED controller can be controlled remotely.
Further advantages and functions
Synchronous switching and dimming via several LED controllers Time-controlled switching on and off Soft On/Off (soft switching on and off) Delayed switching on and off Energy-efficient and durable with extremely low heat generation Integrated logic module with unlimited IF-THEN functions in the system, e.g. different brightness during the day than at night or e.g. flashing function when the doorbell is pressed.
